Elenos ETG2000

Elenos ETG2000 FM Transmitter 2000 Watts

The 2U transmitter 2KW maximizes the concepts of energy efficiency, compactness and reliability that have steered the design over the past ten years. All the transmitters in
this line are extremely compact and light, which makes for greater ease in their installation and lower transportation costs.

Their high energy efficiency also allows for a considerably lower operating cost.

The line is also characterized by extremely high reliability and the ability to ensure high performance even under extreme operating conditions due to intelligent safety protocols, Icefet technology, and Lifextender algorithms.

The intelligent safety protocols are activated proportionately to the severity of the environmental condition, thus guaranteeing the maximum power output in respect to the safety of the equipment.

To combat high humidity conditions, all circuit boards are protected with a spray coating to prevent corrosion or shorting. An aluminum chassis is used to further avoid corrosion. To combat humidity, Elenos pays particular attention to the air flow inside the transmitter. These are some of the things that make Elenos transmitters so reliable. They use multiple fans for cooling, however all of the fans can stop running and the transmitter will stay on the air – albeit at reduced power. By doing these things, Elenos ensures that the transmitter can work in the most extreme environmental conditions.

Features:

High efficiency
Extremely low-power consumption
and reduced operating costs.

Smart functions/synaptic functions
Extraordinary performance level through
the use of powerful operational algorithms
and inter-module communications within
the transmitter. These software algorithms
adapt the transmitter to environmental
conditions or to any connected device,
preventing poor RF operation or diminished
audio quality.

Very compact size and condensed power
Two rack units in height, with a weight
of less than 14 kilograms (30.8 lbs),
unmatched power versus volume and power
versus weight ratio.

Planar technology
Exceptional stability, repeatability, reliability
and ease of maintenance through the use
of planar technology within the entire RF
section (RF modules, combiners, splitter
and low-pass filter). This allows for the
minimization of internal connections and
soldering, which increases the long term
operation and performance.

Connected everywhere
The remote control and management
features allow users to receive data and
send instructions to the transmitter via
several state-of-the-art communication
channels — SMS, GPRS, TCP/IP and SNMP.

Datasheet:
